As mentioned below in this blog the earphones I am using are far from comfortable. Also, in low light conditions it is hard to read the dial. To modify or not? I would not do anything that could not be reversed (at least at this point). However, the use of the HW-8 would be greatly enhanced with certain mods such as improved audio and being able to read the dial and know the radio is powered up in all light conditions.
Well, the HW-8 works, but it needs help. I guess that is to be expected for a radio of its vintage. The receiver is hot, but too many of the stations heard are in one spot (hi). I worked stations in the first hour of this past weekend’s WES, but it was difficult. I listened to the radio on 40 meters during the daylight hours on a web SDR receiver and the signal sounded clean.
I am not sure where to go from here. Alignment is in order, but lack of test equipment and aging coil cores have me concerned. I do have the alignment tool I believe from my HW-7 build so so many years ago but am just not sure whether it is worth the risk of the cores breaking. Having the VFO a lot closer to frequency would be nice. Also, I have to get headphones that are a lot more comfortable to wear or take the plunge and modify the radio.
For some reason I just feel bugs are the best keys to use with my QRP radios. It is not for the lack of keyers I could use.
The HW-8 arrived at ~19:15 local time last night. It was well packed and in very good physical condition. The first step was to put Anderson Powerpoles on the power leads. Next was to turn the HW-8 on and see how my WWII headphones worked after being on the shelf unused for over 55 years. They worked like a charm! So far, I only tried the little radio on 40 meters. I listened and had a POTA contact with a park in Texas. All I noted so far is (only on 40 meters):
In December 2021 I attempted entry into ham radio nostalgia with the purchase on eBay of an HW-16. Although the HW-16 is not representative of my early days in Ham Radio it was a manageable substitute. Thanks to FedEx it turned out to be only a shipping cost to me and the return of a damaged radio to the seller. Fast forward to March/April 2024 and I am waiting for an HW-8 purchased from an ad on QRZ.com. The funds have been sent to the seller and I am waiting to receive the radio with fingers crossed. Will it be received at all and if so, will it be in good shape and will it be as advertised. Stay tuned.
Note: Back in the day I built an HW-7. I do not remember what happened to that radio.
Yes, it was fun to build and operate, but it is just not right. The FREQ-Mite audio level is too high (even after increasing the inline resistor to one megohm), and the RF power output is too low. Lacking any real test equipment (such as a means to measure inductance) I am not sure the little radio will ever be what should be. The question is: will the NorCal 40B make its way back to the operating desk or just become a knickknack on the shelf? Time will tell, but at this point my hopes are not very high.
Footnote: The morning after the above post just before pulling the NorCal 40B offline I had a very nice QSO with a station about 580 miles away. So even at a max of 1.5 watts out I can still work other stations and have a real QSO. It is important to point out the other station was very loud in North Georgia.
This is the semi-finished NorCal 40B. (I chose to place the FREQ-Mite’s activation bottom above the RIT switch.) I am not sure the little radio will ever be finished. It is more and experiment than a anything else. I added up to a one megohm resistor to the audio line from the FREQ-Mite and the level is still too high. The power output appears to be too low, but my measuring devices are not all that precise. I do not have any real test equipment just a DMM, an Elecraft W1 Power Meter (kit built) and a home-built RF probe. That said it was fun to build, enjoy following all the web chatter about the radio and I can have nice QSO’s with the little thing. It was especially enjoyable and interesting to build the transceiver by circuit stage. I am ready to build more stuff!
The FREQ-Mite is installed in the NorCal 40B. It works, but somehow, I lost 25% of my power output. When there is only 2 watts losing 25%
is a big deal. As I have said many times it is the journey not the destination, this is starting to feel like an endless trip.
The frequency appears to be close to the display on my K3. Also, I have to increase the resistor value in the audio line as the volume is too high.
The FREQ-Mite is working in the test mode. Now to mount it in the NorCal 40B.
The FREQ-Mite was received and is on the bench (actually a table). It came fast and in perfect condition. A parts inventory showed all was received in order.
FREQ-mite received and ready to be built
I started to put the parts on the board. I tend to build these kits slowly as it is the journey not the destination. Although there has to be a destination that includes a functional and useful end result.
Freq-Mite build in process
The once temporary operating position for my QRP radios has become permanent as it is really the only place available (for now). The bug fits nicely behind the small keyboard. My other QRP radio (Penntek TR-25) is standing by at the ready.
I have had several great rag chews over the last two weeks on 40 me
ters during the daylight hours using just two watts output. These QSO’s have been in the 150 to 350 mile range. I have also found that my old Lafeyette Radio bug works better than I remember. I guess over 50 years on the shelf brought out its good side.
